Comprehensive Electrical Testing Facility for Cables, Conductors, Insulation & Electrical Products

Our Laboratory provides a complete testing facility for Electrical and Electricity-related products and services, supporting manufacturers, contractors, infrastructure companies, government organizations, research institutions, and other stakeholders in meeting applicable quality, safety, performance, and reliability requirements.

The laboratory is equipped to execute a wide range of electrical, mechanical, physical, chemical, thermal, environmental, insulation, fire-performance, and safety tests in accordance with applicable BIS, BSS, ASTM, ISO, CPWD, RDSO, JSS, RITES, and other relevant national and international specifications and standards.

Our testing capabilities cover electrical cables, wires, conductors, insulation and sheathing materials, armouring materials, overhead transmission conductors, home appliances, and other electrical products.

Major Electrical & Electricity Testing Services

1. Wire & Conductor Testing

We offer comprehensive testing of wires and conductors to assess their mechanical strength, electrical performance, dimensional characteristics, and compliance with applicable specifications.

• Annealing Test for Wires Used As Conductors

• Tensile Test For Aluminium Wires

• Wrapping Test for Aluminium Wires

• Per sulphate Test of Conductor

• Conductor Resistance Test

• Breaking Load of Messenger wire

• Complete Testing of over head transmission purpose Conductor as per Specification

2. Insulation & Sheath Testing

Our laboratory conducts detailed testing of thermoplastic and elastomeric insulation and sheath materials to evaluate their physical, mechanical, thermal, environmental, and long-term performance.

• Thickness of thermoplastic and Elastomeric Insulation and Sheath

• Tensile Strength and Elongation at Break of Thermoplastic and Elastomeric Insulation and Sheath

• Breaking Strength and Elongation at Break For Impregnated Paper Insulation

• Tear Resistance For Paper Insulation

• Loss of Mass Test

• Thermal Ageing in Air

• Shrinkage Test

• Ozone Resistance Test

• Heat Shock Test

• Hot Deformation Test

• Accelerated Ageing Test by Oxygen Pressure Method

• Tear Resistance Test for heavy Duty Sheath

• Bleeding and Blooming Test

• Cold Bend Test

• Cold Impact Test

• Measurement of Temperature index.

• Vicat Softening Point

• Melt – Flow index

• Environmental Stress Cracking Test

• Hot Set Test

• Oil Resistance Test

• Carbon Content Test For Polyethylene

• Water Absorption Test ( Gravimetric )

• Measurement of Thickness of Metallic Sheath

• Determination of Tin in Lead Alloy for Sheath

3. Insulating Paper Testing

Testing of insulating paper is carried out to determine its chemical, physical, moisture-related, and electrical suitability for insulation applications.

• Water Soluble Imp

• Conductivity of Water Extract Test of Insulating Paper

• pH Value of Water Extract Test of Insulating Paper

• Ash Content Test of Insulating Paper

• Water Absorption Test

4. Armouring Material Testing

We provide testing facilities for metallic armouring materials used in electrical cables, including galvanized steel wires and strips, to evaluate mechanical properties, dimensions, coating uniformity, zinc coating, resistivity, and overall compliance.

• Dimension of Armouring Material

• Tensile Strength and Elongation at Break of Armouring Materials

• Torsion Test on Galvanized steel Wires for Armouring

• Winding Test on Galvanized steel Strips for Armouring.

• Uniformity of Zinc Coating on Steel Armour

• Mass of Zinc Coating on Steel Armour

• Resistivity Test of Armour Wires and Strips and Conductance Test of Armour ( Wires/Strips)

5. Electrical Performance & High-Voltage Testing

Our electrical testing capabilities help assess the insulation integrity, dielectric performance, electrical resistance, high-voltage withstand capability, and overall electrical reliability of cables and electrical components.

• Insulation Resistance

• Spark Test

• High Voltage Test

• Partial Discharge Test

• Impulse Test

• Dielectric Power Factor Test

• Heating Cycle Test

6. Cable Mechanical & Physical Testing

Mechanical and physical tests help determine the durability, flexibility, resistance, and performance of electrical cables under different operating and environmental conditions.

• Bending Test

• Dripping Test

• Drainage Test

• Static Flexibility Test

• Abrasion Test

• Flexing Test

7. Thermal, Ageing & Environmental Testing

Environmental and accelerated ageing tests help evaluate the ability of insulation, sheathing, and cable materials to withstand elevated temperatures, pressure, environmental exposure, and long-term service conditions.

• Accelerated Ageing Test By Air Pressure Method

• Thermal Stability of PVC Insulation And Sheath

• Heating Cycle Test

• Ozone Resistance Test

• Environmental Stress Cracking Test

• Cold Bend Test

• Cold Impact Test

• Oil Resistance Test

• Hot Set Test

8. Fire Performance & Flame Testing of Electrical Cables

Our laboratory provides fire-performance testing to evaluate the behaviour of electrical cables and polymeric materials when exposed to flame, heat, and combustion conditions.

• Flammability Test

• Flame Retardant Test

• Flame Retardant Test For Bunched Cables

• Oxygen Index Test

• Determination of the Amount of Halogen Acid Gas Evolved During Combustion of Polymeric Materials Taken From Cable

• Measurement of Smoke Density of Electric Cables Under Fire Conditions

9. Home Appliance Safety & Dimension Testing

We provide Safety and Dimension Testing for home appliances to help assess products against applicable safety, dimensional, and performance requirements.

• Safety and Dimension Testing for home appliances

Testing Across Multiple Quality & Compliance Requirements

Our testing services are designed to support conformity assessment and product quality requirements under applicable:

• BIS Standards

• BSS Standards

• ASTM Standards

• ISO Standards

• CPWD Specifications

• RDSO Specifications

• JSS Specifications

• RITES Specifications

• Other applicable national and international specifications

Why Choose Our Electrical Testing Laboratory?

Comprehensive Testing Capability

A broad range of electrical, mechanical, physical, chemical, thermal, environmental, insulation, and fire-performance tests can be conducted under one laboratory facility.

Standards-Based Testing

Testing is performed with reference to applicable national and international standards and specifications, helping organizations demonstrate product quality and conformity.

Wide Product Coverage

Our capabilities cover wires, conductors, electrical cables, insulation, sheathing, armouring materials, overhead transmission conductors, home appliances, and related electrical products.

Quality & Reliability

Our testing approach focuses on generating dependable test results that can support quality control, product development, compliance assessment, and performance evaluation.

Supporting Electrical Product Quality & Compliance

From conductor resistance and tensile testing to high voltage, partial discharge, impulse, dielectric power factor, ageing, fire-retardant, oxygen index, halogen acid gas, and smoke density testing, our laboratory provides a comprehensive range of testing services for electrical and electricity-related products.

Whether you require routine quality testing, product validation, specification compliance, research and development testing, or performance evaluation, our laboratory offers a broad testing infrastructure to support your electrical testing requirements.
